FOUR WHEEL DRIVE


Engaged by a single lever, 4WD is standard on the CX Series tractors.

DUAL PEDAL, 2 RANGE HST

Easier and more comfortable than rocker pedals.

HYDRAULIC PTO


Hydraulic PTO clutch offers great durability and ease of use. Simply rotate the knob to engage or disengage the PTO.

MANUAL & HST TRANSMISSION


The manual transmission model features 6F/2R speeds. The HST model utilizes a performance proven, heavy - duty HST that delivers power smoothly and efficiently. With the HST drive your hands remain free for steering and implement control.

FOLDABLE ROPS


The standard fold-down roll bar makes it quick and easy to maneuver in low clearance areas.

STREAMLINED HOOD DESIGN


Visibility and serviceability are improved for the operator with the sstreamlined hood design. The vertical opening hood allows for easy access to the air filter , fluid service, fuse box, and other major electrical components.

HI/LOW SPEED RANGES


The CX features a two range transmission (Hi/Low) to maximize performance and efficiency.

  • CX2510 Specs

    ENGINE

    Model: 3A165LWH-U2

    Type: Liquid Cooled 4 cyl., Diesel

    Engine Gross (hp): 24.5

    PTO @ Rated PTO rpm (hp): 19.3

    Displacement (cu. in.): 87.0

    Rated Revolution (RPM): 2,600

    Fuel Tank Capacity (US. gal.): 6.6

    DRIVE TRAIN

    Transmission: Manual

    No. of Speeds: 6F/2R

    Differential Lock: Rear Standard

    PTO Type:Transmission

    Mid PTO: 2,000 (option)

    Rear PTO: Standard (540 rpm)

    Brakes: Wet, Multi-Disc

    4WD Type: Mechanical Engagement

    HYDRAULIC SYSTEM

    Pump: Gear

    Pump Capacity (Max. Flow Rate) (GPM): 11.3

    3-Point Hitch: Category 1

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 1,203

    Hydraulic Lift Control System: Position

    Steering: Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 109.3

    Overall Width (Minimum Tread) (in.): 49.4

    Overall Height (From Top of ROPS)  (in): 82.8

    Wheelbase (in.): 59.8

    Min. Ground Clearance (in.): 13.4

    Tread Front (AG.) (in.): 38.1

    Tread Rear (AG.) (in.): 37.4

    Min. Turning Radius (With Brake) (ft): 9.0

    WEIGHT

    Weight with AG. Tires (lb.):  2,308

  • CX2510 HST Specs

    ENGINE

    Model: 3A165LWH-U2

    Type: Liquid Cooled 4 cyl., Diesel

    Engine Gross (hp): 24.5

    PTO @ Rated PTO rpm (hp): 18.8

    Displacement (cu. in.): 87.0

    Rated Revolution (RPM): 2,600

    Fuel Tank Capacity (US. gal.): 6.6

    DRIVE TRAIN

    Transmission: Hydrostatic Drive

    No. of Speeds: Infinite, 2 Ranges

    Differential Lock: Rear Standard

    PTO Type: Live

    Mid PTO: Standard (2000 rpm)

    Rear PTO: Standard (540 rpm)

    Brakes: Wet, Multi-Disc

    4WD Type: Mechanical Engagement

    HYDRAULIC SYSTEM

    Pump: Gear

    Pump Capacity (Max. Flow Rate) (GPM): 11.3

    3-Point Hitch: Category 1

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 1,203

    Hydraulic Lift Control System: Position

    Steering: Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 109.3

    Overall Width (Minimum Tread) (in.): 49.4

    Overall Height (From Top of ROPS)  (in): 82.8

    Wheelbase (in.): 59.8

    Min. Ground Clearance (in.): 13.4

    Tread Front (AG.) (in.): 38.1

    Tread Rear (AG.) (in.): 37.4

    Min. Turning Radius (With Brake) (ft): 9.0

    WEIGHT

    Total weight without ballast (lbs.): 2,308

  • CX2510 HST Cab Specs

    ENGINE

    Model: 3A165LWH-U3

    liquid Cooled 34cyl., Diesel

    Engine Gross (hp): 24.5

    PTO @ Rated PTO rpm (hp): 18.8

    Displacement (cu. in.): 87.0

    Rated Revolution (RPM): 2,600

    Fuel Tank Capacity (US. gal.): 6.6

    DRIVE TRAIN

    Transmission: Hydrostatic Drive

    No. of Speeds: Infinite, 2 Ranges

    Differential lock: Rear Standard

    PTO Type: Independent

    Mid PTO: Standard (2000 rpm)

    Rear PTO: Standard (540 rpm)

    Brakes: Wet, Multi-Disc

    4WD Type: Mechanical Engagement

    HYDRAULIC SYSTEM

    Pump: Gear

    Pump Capacity (Max. Flow Rate) (GPM): 11.3

    3-Point Hitch: Category 1

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 1,203

    Hydraulic Lift Control System: Position

    Steering: Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 111

    Overall Width (Minimum Tread) (in.): 49.4

    Overall Height (From Top of CAB)  (in): 86.6

    Wheelbase (in.): 59.8

    Min. Ground Clearance (in.): 13.4

    Tread Front (AG.) (in.): 38.1

    Tread Rear (AG.) (in.): 37.4

    Min. Turning Radius (With Brake) (ft): 9.0

    WEIGHT

    Total weight without ballast (lbs.): 2,804

  • Loader Specs

    FRONT END LOADER – KL2510
    Maximum Lift Height (to Pivot Pin): 87.8 in.

    Clearance w/ Bucket Level: 84.3 in.

    Clearance w/ Bucket Dumped: 67.2 in.

    Reach at Maximum Height: 31.5 in.

    Maximum Dump angle: 53

    Reach w/ Bucket on Ground: 59.8

    Maximum Rollback Angle: 35

    Digging Depth Below Grade: 3.9 in.

    Overall Height (in Carry Position): 40.0 in.

    Depth of Bucket (to back of inner shell): 19.9 in.

    Height of Bucket: 20.7 in.

    Length of Bucket (to pivot pin): 26.9

    Lift of Bucket Capacity to Full Height (at Pivot Pins): 1,092 lbs.

    Breakout Force (at Pivot Pins): 1,843 lbs.

    Bucket Rollback Force (at Ground Line): 1,416

    Relief Valve Setting (Loader Control Valve) 2,275 psi

    Rated Flow (Tractor System): 6.86 gpm

    Bucket Size (QA): 50 in.

    Bucket Capacity (Heaped): 7.8 cu. ft.

    Approximate Weight (With Bucket): 605 bs.
