FOUR WHEEL DRIVE
Engaged by a single lever, 4WD is standard on the CX Series tractors.
DELUXE SUSPENSION SEAT
Provides a comfortable ride fo rthe operator, even on rough terrain.
POWER AND TILT STEERING
Standard power steering reduces effort for tight, repetitive turns. The tilting steering wheel adjusts easily with a push of a lever to fit operator needs.
DUAL PEDAL, 2 RANGE HST
Easier and more comfortable than rocker pedals.
HYDRAULIC PTO
Hydraulic PTO clutch offers great durability and ease of use. Simply rotate the knob to engage or disengage the PTO.
MANUAL & HST TRANSMISSION
The manual transmission model features 6F/2R speeds. The HST model utilizes a performance proven, heavy - duty HST that delivers power smoothly and efficiently. With the HST drive your hands remain free for steering and implement control.
FOLDABLE ROPS
The standard fold-down roll bar makes it quick and easy to maneuver in low clearance areas.
HIGH-CAPACITY HYDRAULIC PUMP
A high-capacity efficient tandem hydraulic pump provides a smoother handling in heavy-duty working conditions. Provides smooth and consistent hydraulic flow to increase operator productivity.
REAR HYDRAULIC REMOTES
A standard single remote valve, with an optional second valve, accommodates a wide range of attachments and implements (SE models only)
-
DK4520 Specs
ENGINE
Engine Gross (hp): 44.9
PTO @ Rated PTO rpm (hp): 38.9
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 11.9
DRIVE TRAIN
Clutch: Dry Single Stage
Transmission: Synchronized Shuttle
No. of Speeds: 8F/8R
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 14.56
3-Point Hitch: Category 1
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 1
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2 Optional
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 124.3
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of ROPS) (in): 96.8
Wheelbase (in.): 71.3
-
DK5020 Specs
ENGINE
Engine Gross (hp): 50.3
PTO @ Rated PTO rpm (hp): 41.5
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 11.9
DRIVE TRAIN
Clutch: Dry Single Stage
Transmission: Synchronized Shuttle
No. of Speeds: 8F/8R
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 14.56
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 1
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2 Optional
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 124.3
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of ROPS) (in): 96.8
Wheelbase (in.): 71.3
-
DK5520 Specs
ENGINE
Engine Gross (hp): 55.0
PTO @ Rated PTO rpm (hp): 46.4
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 11.9
DRIVE TRAIN
Clutch: Dry Single Stage
Transmission: Synchronized Shuttle
No. of Speeds: 8F/8R
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 14.56
3-Point Hitch: Category 2
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 1
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2 Optional
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 124.3
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of ROPS) (in): 96.8
Wheelbase (in.): 71.3
-
DK4220SEH Specs
ENGINE
Engine Gross (hp): 39.6
PTO @ Rated PTO rpm (hp):29.1
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 12.7
DRIVE TRAIN
Transmission:Hydrostatic
No. of Speeds: 3 Range
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 16.49
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 1
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 125.5
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of ROPS) (in): 96.8
Wheelbase (in.): 71.3
-
DK4200SEH Cab Specs
ENGINE
Engine Gross (hp): 44.9
PTO @ Rated PTO rpm (hp): 33.4
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 12.7
DRIVE TRAIN
Transmission:Hydrostatic
No. of Speeds: 3 Range
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 16.49
3-Point Hitch: Category 1
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 1
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 125.5
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of Cab) (in): 93.0
Wheelbase (in.): 71.3
-
DK4720SEH Specs
ENGINE
Engine Gross (hp): 44.9
PTO @ Rated PTO rpm (hp): 33.4
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 12.7
DRIVE TRAIN
Transmission:Hydrostatic
No. of Speeds: 3 Range
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 16.49
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 1
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 125.5
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of ROPS) (in): 96.8
Wheelbase (in.): 71.3
-
DK4720SEH Cab Specs
ENGINE
Engine Gross (hp): 44.9
PTO @ Rated PTO rpm (hp): 33.4
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 12.7
DRIVE TRAIN
Transmission:Hydrostatic
No. of Speeds: 3 Range
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 16.49
3-Point Hitch: Category 1
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 1
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 125.5
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of Cab) (in): 93.0
Wheelbase (in.): 71.3
-
DK5320HSE Specs
ENGINE
Engine Gross (hp): 50.3
PTO @ Rated PTO rpm (hp): 39.3
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 12.7
DRIVE TRAIN
Transmission:Hydrostatic
No. of Speeds: 3 Range
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 16.49
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 1
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 125.5
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of ROPS) (in): 96.8
Wheelbase (in.): 71.3
-
DK5320HSE Cab Specs
ENGINE
Engine Gross (hp): 50.3
PTO @ Rated PTO rpm (hp): 39.3
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 12.7
DRIVE TRAIN
Transmission:Hydrostatic
No. of Speeds: 3 Range
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 16.49
3-Point Hitch: Category 1
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 1
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 125.5
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of Cab) (in): 93.0
Wheelbase (in.): 71.3
-
DK6020HSE Specs
ENGINE
Engine Gross (hp): 57.7
PTO @ Rated PTO rpm (hp): 44.9
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 12.7
DRIVE TRAIN
Transmission:Hydrostatic
No. of Speeds: 3 Range
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 16.49
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 2
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 125.5
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of Cab) (in): 93.0
Wheelbase (in.): 71.3
-
DK6020HSE Cab Specs
ENGINE
Engine Gross (hp): 57.7
PTO @ Rated PTO rpm (hp): 44.9
Displacement (cu. in.): 111.4
Rated Revolution (RPM): 2,600
Fuel Tank Capacity (US. gal.): 12.7
DRIVE TRAIN
Transmission:Hydrostatic
No. of Speeds: 3 Range
Differential Lock: Rear Standard
PTO Type: Transmission
Rear PTO: Standard (540 rpm)
Brakes: Wet, Disc
4WD Type: Manual
HYDRAULIC SYSTEM
Pump: Gear
Pump Capacity (Max. Flow Rate) (GPM): 16.49
Maximum Lifting Capacity (24" aft. of hitch) (lb.): 2,716.0
3-Point Hitch: Category 2
Hydraulic Lift Control System: Position
No. Of Standard Remote Valves: 2
Steering: Hydraulic Power Steering
DIMENSIONS
Overall Length (Includes 3-pt Hitch.) (in): 125.5
Overall Width (Minimum Tread) (in.): 62.8
Overall Height (From Top of Cab) (in): 93.0
Wheelbase (in.): 71.3
-
Loader Specs
FRONT END LOADER – KL5520 / KL5521
Maximum Lift Height (to Pivot Pin): 107.7in.Clearance w/ Bucket Level: 96.3 in.
Clearance w/ Bucket Dumped: 78.8 in.
Reach at Maximum Height: 22.7 in.
Reach w/ Bucket on Ground: 71.1
Maximum Rollback Angle: 41
Digging Depth Below Grade: 8.6 in.
Overall Height (in Carry Position): 54.0 in.
Depth of Bucket (to back of inner shell): 22.0 in.
Height of Bucket: 22.0 in.
Length of Bucket (to pivot pin): 26
Lift of Bucket Capacity to Full Height (at Pivot Pins): 2,474 lbs.
Breakout Force (at Pivot Pins): 3,89 lbs.
Bucket Rollback Force (at Ground Line): 1,416
Bucket Size (QA): 66.0 / 72.0 in.
Bucket Capacity (Heaped) in3 : 66 / 72
Approximate Weight (With Bucket): 605 bs.
-
