PUSH BUTTON 4 WHEEL DRIVE


4WD is engaged with the simple push of a botton. Auto 4WD engagement allows for increased brake performance.

POWER SHUTTLE LEVER


Effortlessly change forward and reverse direction with the Power Shuttle Lever, no clutch pedal required.

PTO CRUISE CONTROL

With one touch, engine speed can be set to maintain a steady RPM for maximum working efficiency. Once engaged, operators can easily adjust RPM up or down with a simple switch.

ELECTRONIC 3-POINT HITCH


Allows for effortless implement control with the flick of a wrist. Takes the guesswork out of raising and lowering implements, ensuring precise height positioning and operator comfort.

REMOTE HYDRAULIC VALVES AND JOYSTICK

Standard single lever joystick for easy loader or front implement operation. A standard single remote valve (additional valves optional) accommodate a wide variety of attachments and implements.

EXTERNAL HYDRAULIC LIFT CYLINDER


Two external hydraulic lift cylinders make maintenance easier and increase lift capacity up to 4,378 pounds.

  • RX6640P Specs

    ENGINE

    Model: 4H243T

    Type: KIOTI 4 Cylinder, in-line Vertical, Water-Cooled 4 Cycle Turbo Diesel, CRDI

    Engine Gross (hp): 66.4

    PTO @ Rated PTO rpm (hp): 54.9

    Displacement (cu. in.): 2,435

    Rated Revolution (RPM): 2,600

    Fuel Tank Capacity (US. gal.): 26.4

    DRIVE TRAIN

    Clutch: Wet Disc

    Transmission: Power Shuttle

    No. of Speeds: 12F/12R

    Differential Lock: Rear Standard

    PTO Type: Independent

    Rear PTO: Standard (540/540E rpm)

    Brakes: Wet, Multi-Disc

    4WD Type: Electric/Hydraulic

    HYDRAULIC SYSTEM

    Pump: Tandem Gear

    Pump Capacity (Max. Flow Rate) (GPM): 20.6

    3-Point Hitch: Category 2

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 4,327.7

    Hydraulic Lift Control System: Electronic Control w/ Dual External Lift Cylinders

    No. of Standard Remote Valves: 1 Standard (1 Optional ROPS, 1 Optional CAB)

    Steering: Hydrostatic Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 150.3

    Overall Width (Minimum Tread) (in.): 82.1

    Overall Height (From Top of ROPS)  (in): 114.8

    Wheelbase (in.): 85.4

    Min. Ground Clearance (in.): 15.75

    Min. Turning Radius (With Brake) (ft): 12.8

    WEIGHT

    Weight with AG. Tires (lb.):  6,051

  • RX6640PC Specs

    ENGINE

    Model: 4H243T

    Type: KIOTI 4 Cylinder, in-line Vertical, Water-Cooled 4 Cycle Turbo Diesel, CRDI

    Engine Gross (hp): 66.4

    PTO @ Rated PTO rpm (hp): 54.9

    Displacement (cu. in.): 2,435

    Rated Revolution (RPM): 2,600

    Fuel Tank Capacity (US. gal.): 26.4

    DRIVE TRAIN

    Clutch: Wet Disc

    Transmission: Power Shuttle

    No. of Speeds: 12F/12R

    Differential Lock: Rear Standard

    PTO Type: Independent

    Rear PTO: Standard (540/540E rpm)

    Brakes: Wet, Multi-Disc

    4WD Type: Electric/Hydraulic

    HYDRAULIC SYSTEM

    Pump: Tandem Gear

    Pump Capacity (Max. Flow Rate) (GPM): 20.6

    3-Point Hitch: Category 2

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 4,327.7

    Hydraulic Lift Control System: Electronic Control w/ Dual External Lift Cylinders

    No. of Standard Remote Valves: 1 Standard (1 Optional ROPS, 1 Optional CAB)

    Steering: Hydrostatic Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 150.3

    Overall Width (Minimum Tread) (in.): 82.1

    Overall Height (From Top of CAB)  (in): 105.3

    Wheelbase (in.): 85.4

    Min. Ground Clearance (in.): 15.75

    Min. Turning Radius (With Brake) (ft): 12.8

    WEIGHT

    Weight with AG. Tires (lb.):  6,814

  • RX7340P Specs

    ENGINE

    Model: 4H243T

    Type: KIOTI 4 Cylinder, in-line Vertical, Water-Cooled 4 Cycle Turbo Diesel, CRDI

    Engine Gross (hp): 73.1

    PTO @ Rated PTO rpm (hp): 60.9

    Displacement (cu. in.): 2,435

    Rated Revolution (RPM): 2,600

    Fuel Tank Capacity (US. gal.): 26.4

    DRIVE TRAIN

    Clutch: Wet Disc

    Transmission: Power Shuttle

    No. of Speeds: 12F/12R

    Differential Lock: Rear Standard

    PTO Type: Independent

    Rear PTO: Standard (540/540E rpm)

    Brakes: Wet, Multi-Disc

    4WD Type: Electric/Hydraulic

    HYDRAULIC SYSTEM

    Pump: Tandem Gear

    Pump Capacity (Max. Flow Rate) (GPM): 20.6

    3-Point Hitch: Category 2

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 4,327.7

    Hydraulic Lift Control System: Electronic Control w/ Dual External Lift Cylinders

    No. of Standard Remote Valves: 1 Standard (1 Optional ROPS, 1 Optional CAB)

    Steering: Hydrostatic Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 150.3

    Overall Width (Minimum Tread) (in.): 82.1

    Overall Height (From Top of ROPS)  (in): 114.8

    Wheelbase (in.): 85.4

    Min. Ground Clearance (in.): 15.75

    Min. Turning Radius (With Brake) (ft): 12.8

    WEIGHT

    Weight with AG. Tires (lb.):  6,252

  • RX7340PC Specs

    ENGINE

    Model: 4H243T

    Type: KIOTI 4 Cylinder, in-line Vertical, Water-Cooled 4 Cycle Turbo Diesel, CRDI

    Engine Gross (hp): 73.1

    PTO @ Rated PTO rpm (hp): 60.9

    Displacement (cu. in.): 2,435

    Rated Revolution (RPM): 2,600

    Fuel Tank Capacity (US. gal.): 26.4

    DRIVE TRAIN

    Clutch: Wet Disc

    Transmission: Power Shuttle

    No. of Speeds: 12F/12R

    Differential Lock: Rear Standard

    PTO Type: Independent

    Rear PTO: Standard (540/540E rpm)

    Brakes: Wet, Multi-Disc

    4WD Type: Electric/Hydraulic

    HYDRAULIC SYSTEM

    Pump: Tandem Gear

    Pump Capacity (Max. Flow Rate) (GPM): 20.6

    3-Point Hitch: Category 2

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 4,327.7

    Hydraulic Lift Control System: Electronic Control w/ Dual External Lift Cylinders

    No. of Standard Remote Valves: 1 Standard (1 Optional ROPS, 1 Optional CAB)

    Steering: Hydrostatic Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 150.3

    Overall Width (Minimum Tread) (in.): 82.1

    Overall Height (From Top of CAB)  (in): 105.3

    Wheelbase (in.): 85.4

    Min. Ground Clearance (in.): 15.75

    Min. Turning Radius (With Brake) (ft): 12.8

    WEIGHT

    Weight with AG. Tires (lb.):  7,015

  • RX7340PCR Specs

    ENGINE

    Model: 4H243T

    Type: KIOTI 4 Cylinder, in-line Vertical, Water-Cooled 4 Cycle Turbo Diesel, CRDI

    Engine Gross (hp): 73.1

    PTO @ Rated PTO rpm (hp): 60.9

    Displacement (cu. in.): 2,435

    Rated Revolution (RPM): 2,600

    Fuel Tank Capacity (US. gal.): 26.4

    DRIVE TRAIN

    Clutch: Wet Disc

    Transmission: Power Shuttle

    No. of Speeds: 20F/20R

    Differential Lock: Rear Standard

    PTO Type: Independent

    Rear PTO: Standard (540/540E rpm)

    Brakes: Wet, Multi-Disc

    4WD Type: Electric/Hydraulic

    HYDRAULIC SYSTEM

    Pump: Tandem Gear

    Pump Capacity (Max. Flow Rate) (GPM): 20.6

    3-Point Hitch: Category 2

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 4,327.7

    Hydraulic Lift Control System: Electronic Control w/ Dual External Lift Cylinders

    No. of Standard Remote Valves: 1 Standard (1 Optional ROPS, 1 Optional CAB)

    Steering: Hydrostatic Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 150.3

    Overall Width (Minimum Tread) (in.): 82.1

    Overall Height (From Top of CAB)  (in): 105.3

    Wheelbase (in.): 85.4

    Min. Ground Clearance (in.): 15.75

    Min. Turning Radius (With Brake) (ft): 12.8

    WEIGHT

    Weight with AG. Tires (lb.):  7,015

  • Loader Specs

    FRONT END LOADER – KL7340

    Maximum Lift Height (to Pivot Pin): 127.1

    Clearance w/ Bucket Level: 116.22

    Clearance w/ Bucket Dumped: 93.58 in.

    Reach at Maximum Height: 1 7.4 in.

    Maximum Dump angle: 55

    Reach w/ Bucket on Ground: 83.62

    Maximum Rollback Angle: 51

    Digging Depth Below Grade: 6.22 in.

    Overall Height (in Carry Position): 69.37 in.

    Lift of Bucket Capacity to Full Height (at Pivot Pins): 3,300 lbs.

    Breakout Force (at Pivot Pins): 5,875 lbs.

    Bucket Rollback Force (at 800mm): 4,118

    Relief Valve Setting (Loader Control Valve) 2,560

    Rated Flow (Tractor System): 6.86 gpm

    Bucket Size (QA): 81.89 in.

    Bucket Capacity (Heaped): 21.19 cu. ft.
