FOUR WHEEL DRIVE


Engaged by a single lever, 4WD is standard on the CX Series tractors.

HYDRAULIC PTO


Hydraulic PTO clutch offers great durability and ease of use. Simply rotate the knob to engage or disengage the PTO.

SHUTTLE SHIFT MANUAL TRANSMISSION


The manual transmission model features 24F/24R speeds.

STREAMLINED HOOD DESIGN


Visibility and serviceability are improved for the operator with the sstreamlined hood design. The vertical opening hood allows for easy access to the air filter , fluid service, fuse box, and other major electrical components.

  • HX9010 Specs

    ENGINE

    Model: 4J243TA-TP5B

    Engine Gross (hp): 90

    PTO @ Rated PTO rpm (hp): 70

    Displacement (cu. in.): 233.90

    Rated Revolution (RPM): 2,200

    Fuel Type: Diesel

    Aspiration: Intercular

    Fuel Tank Capacity (US. gal.): 47.60

    DRIVE TRAIN

    Transmission: Manual Power Shuttle

    No. of Speeds: 24F/24R

    PTO Type:Independent

    Rear PTO: 540 / 540E / 1000

    Brakes: Wet, Multi-Disc

    4WD Type: Mechanical Engagement

    HYDRAULIC SYSTEM

    Pump: Gear

    Pump Capacity (Max. Flow Rate) (GPM): 32

    3-Point Hitch: Category 2

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 8,002

    Control Type: Electronic

    Steering: Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 170.78

    Overall Width (Minimum Tread) (in.): 88.58

    Overall Height (From Top of Cab)  (in): 111.93

    Wheelbase (in.): 94.88

    Min. Ground Clearance (in.): 18.94

    Tread Front (AG.) (in.): 65.35

    Tread Rear (AG.) (in.): 70.47

    Min. Turning Radius (With Brake) (ft): 12.69

    WEIGHT

    Weight with AG. Tires (lb.):  10,230

  • HX1151 Specs

    ENGINE

    Model: 4J243TA-TP5B

    Engine Gross (hp): 115.30

    PTO @ Rated PTO rpm (hp): 83.90

    Displacement (cu. in.): 233.90

    Rated Revolution (RPM): 2,200

    Fuel Type: Diesel

    Aspiration: Intercular

    Fuel Tank Capacity (US. gal.): 47.60

    DRIVE TRAIN

    Transmission: Manual Power Shuttle

    No. of Speeds: 24F/24R

    PTO Type:Independent

    Rear PTO: 540 / 540E / 1000

    Brakes: Wet, Multi-Disc

    4WD Type: Mechanical Engagement

    HYDRAULIC SYSTEM

    Pump: Gear

    Pump Capacity (Max. Flow Rate) (GPM): 32

    3-Point Hitch: Category 2

    Maximum Lifting Capacity (24" aft. of hitch) (lb.): 8,002

    Control Type: Electronic

    Steering: Power Steering

    DIMENSIONS

    Overall Length (Includes 3-pt Hitch.) (in): 170.78

    Overall Width (Minimum Tread) (in.): 88.58

    Overall Height (From Top of Cab)  (in): 111.93

    Wheelbase (in.): 94.88

    Min. Ground Clearance (in.): 18.94

    Tread Front (AG.) (in.): 65.35

    Tread Rear (AG.) (in.): 70.47

    Min. Turning Radius (With Brake) (ft): 12.69

    WEIGHT

    Weight with AG. Tires (lb.):  10,230

  • Loader Specs

    FRONT END LOADER – KL155
    Maximum Lift Height (to Pivot Pin): 87.8 in.

    Clearance w/ Bucket Level: 84.3 in.

    Clearance w/ Bucket Dumped: 67.2 in.

    Reach at Maximum Height: 31.5 in.

    Maximum Dump angle: 53

    Reach w/ Bucket on Ground: 59.8

    Maximum Rollback Angle: 35

    Digging Depth Below Grade: 3.9 in.

    Overall Height (in Carry Position): 40.0 in.

    Depth of Bucket (to back of inner shell): 19.9 in.

    Height of Bucket: 20.7 in.

    Length of Bucket (to pivot pin): 26.9

    Lift of Bucket Capacity to Full Height (at Pivot Pins): 1,092 lbs.

    Breakout Force (at Pivot Pins): 1,843 lbs.

    Bucket Rollback Force (at Ground Line): 1,416

    Relief Valve Setting (Loader Control Valve) 2,275 psi

    Rated Flow (Tractor System): 6.86 gpm

    Bucket Size (QA): 50 in.

    Bucket Capacity (Heaped): 7.8 cu. ft.

    Approximate Weight (With Bucket): 605 bs.
