Backhoe

LB2106

  • Digging Depth (in): 89.7
  • Reach from centerline of swing Pivot (in): 125.2
  • Loading Height (in): 72.4
  • Swing Arc (deg.): 180
  • Transport Height (in): 83.5
  • Bucket Rotating (deg.): 180
  • Stabilizer Spread(Down position) (in): 68.7
  • Stabilizer Spread(Up position) (in): 46.5
  • Bucket Digging force (lbs): 2,673

Snowblower

LW3174

  • Overall width, inches: 74
  • Cutting width, inches: 74
  • Cutting height, inches: 26
  • Impeller drive: Gear box
  • Auger drive: #60 chain
  • Auger diameter, inches: 14 3/4
  • Impeller diameter, inches: 23 3/4
  • Number of blades on impeller: 4
  • Chute rotation: hydraulic
  • Adjustable heavy skid shoes: yes, 3 positions, 0”, 1/2”, 1”
  • Auger shear bolt protection: Yes
  • Impeller shear bolt protection: Yes
  • Approx. shipping weight, lbs: 874
