Quick Coupler Plumbing To End of Stick
1 and 2-Way Primary & 2-Way Secondary Auxiliary Circuits
Reversible Hydraulic System Cooling Fan
Rear View Camera & Blind Side Camera
Large Touchscreen Display
Removable Counterweight
Heated Air Ride Suspension Seated w/ Adjustable Armrests
Bright LED Work Light Package
Overall Dimensions
Boom Length: 23' ft
Transport Length: 39' 11"
Transport Width: 11' 11"
Transport Height: 12' 8"
Upper Structure Width: 10' 10"
Cab Height: 11' 3"
Track Width (standard shoe): 35"
Track Gauge: 9'
Ground Clearance (minimum): 22"
Tail Swing Radius: 12' 8"
Track Length on Ground: 14' 6"
Track Length: 17' 11"
Technical Specifications
Operating Weight: 120,152 lb
Ground Pressure: 8.6 psi
Engine: Cummins QSG12
Displacement: 720.1 in3
Gross Power: 400 HP
Hydraulics: Positive Flow Control with Pilot Control
Main Hydraulic Pump: Axial Piston - Variable Displacement
Operating Flow (maximum): 190.2 gal/min
Operating Pressure (maximum): 4,975 psi
Travel Motor: Axial Piston with Park Brake
Travel Pressure (maximum): 4,975 psi
Travel Speeds (maximum): 2.1 / 3.2 mph
Travel Effort (maximum): 48,109 lbf
Grade Capability: 35º
Swing Motor: Axial Piston with Swing Brake
Swing Pressure (maximum): 3,989 psi
Swing Speed (maximum): 8.0 RPM
Undercarriage (standard): Steel Track
Track Shoe Width (standard): 35"
Track Rollers (per side): 9
Carrier Rollers (per side): 2
Working Range
Boom Length: 23' ft
Stick (Arm) Length: 11ft
Maximum Digging Height: 35' 10"
Maximum Dumping Height: 25' 1"
Maximum Digging Depth: 25' 3"
Maximum Vertical Wall Digging Depth: 20' 7"
Maximum Reach at Ground Level: 39' 5"
Minimum Swing Radius: 17' 1"
