Powerful Duetz Engine
Auxiliary Hydraulic Connections On The Boom
Single, Multi-Function Joystick Controls
Full 4-Wheel Fender Package
Backup Camera and Reverse Sensing System
Backup Camera and Reverse Sensing System
Cushioned Solid Tires
Led Boom Work Lights and Lift Hook
Overall Dimensions
Maximum Lift Height: 44' 0"
Maximum Forward Reach: 30' 0"
Height, Stowed: 8' 4"
Length, Stowed (Without Forks): 20' 2"
Width: 8' 1"
Wheelbase: 11' 3"
Ground Clearance (Center): 1' 6"
Ground Clearance (Axle): 1' 5"
Weight: 25,647 lbs
Performance
Maximum Lift Capacity: 8,000 lbs
Lift Capacity at Maximum Height: 6,000 lbs
Lift Capacity at Maximum Reach: 1,500 lbs
Boom (Raise/Lower): 13 seconds / 13 seconds
Boom (Extend/Retract): 16 seconds / 16 seconds
Frame Leveling +/- 10 degrees
Maximum Drive Speed: 14 mph
Outside Turning Radius (4WS): 14' 1"
Auxiliary Hydraulic Flow: 17 gpm
Auxiliary Hydraulic Pressure: 2,466 psi
Standard Tire Size: 13.00-24
Capacities
Power: 74 hp
Torque: 360 lbf-ft
Electrical System: 24 volt
Hydraulic Tank Capacity: 33 gal
Hydraulic System Capacity: 42 gal
Fuel Tank Capacity: 36 gal
Components
Engine: Deutz TCD 3.6
Transmission: Dana VDT12000
Axles F/R: Dana 212 / Dana 212
Hydraulic Pump: Kawasaki Load Sense Piston Pump
Hydraulic Manifold: Parker
