Quick Coupler Plumbing To End of Stick
1 and 2-Way Primary & 2-Way Secondary Auxiliary Circuits
Reversible Hydraulic System Cooling Fan
Rear View Camera & Blind Side Camera
Large Touchscreen Display
Heated Air Ride Suspension Seated w/ Adjustable Armrests
Bright LED Work Light Package
Overall Dimensions
Boom Length: 21' 4"
Transport Length: 36' 6"
Transport Width: 9' 9"
Transport Height: 12' 3"
Upper Structure Width: 9' 9"
Cab Height: 11' 5"
Track Width (standard shoe): 31"
Track Gauge: 7' 10"
Ground Clearance (minimum): 1' 9"
Tail Swing Radius: 11' 4"
Track Length: 16' 7"
Technical Specifications
Operating Weight: 85,318 lbs
Ground Pressure: 9.9 psi
Engine: Cummins QSL9 Stage V / Tier4F
Displacement: 542 in3
Gross Power: 314 HP
Hydraulics: Positive Flow w/Pilot Control
Main Hydraulic Pump: Axial Piston – Variable Displacement
Operating Flow (maximum): 190 gal/min
Operating Pressure (maximum): 4,975 psi
Travel Motor: Axial Piston with Park Brake
Travel Pressure (maximum): 4,975 psi
Travel Speeds (maximum): 1.9 / 3.1 mph
Travel Effort (maximum): 71,938 lbf
Grade Capability: 35°
Swing Motor: Planetary Drive w/Axial Piston Motors
Swing Pressure (maximum): 4,134 psi
Swing Speed (maximum): 8.8 RPM
Undercarriage (standard): Steel Track
Track Shoe Width (standard): 24"
Track Rollers (per side): 2
Carrier Rollers (per side): 9
Working Range
Boom Length: 21' 4"
Stick (Arm) Length: 10' 6"
Maximum Digging Height: 36' 1"
Maximum Dumping Height: 25'
Maximum Digging Depth: 26' 4"
Maximum Vertical Wall Digging Depth: 26' 3"
Maximum Reach at Ground Level: 36' 9"
Minimum Swing Radius: 13' 8"
