Hydraulic Pilot Controls With Pattern-Change  Selector


Thumb Ready Stick


Rubber Tracks For Ground Preservation On All Models Which Are Retractable Up To 34"

Boom And Standard, Straight Blade Cylinder Guards On All Models + Blade Float on The SY35U


Swing Boom Functionality


Primary Auxiliary Circuit With 1- and 2-Way Flow


True Zero Tail Swing


SY35U Has A Flow Divider

  • Slide title

    Write your caption here
    Button

  • Slide title

    Write your caption here
    Button

  • Slide title

    Write your caption here
    Button

  • Overall Dimensions

    Boom Length: 8' 4"

    Stick (Arm) Length: 4' 7"

    Transport Length: 16' 1"

    Transport Width: 5' 8"

    Transport Height: 8' 5"

    Upper Structure Width: 5' 1"

    Cab Height: 8' 5"

    Blade Height: 14"

    Track Width (standard shoe): 12"

    Track Gauge: 4' 8"

    Ground Clearance (minimum): 12"

    Tail Swing Radius: 2' 10"

    Track Length on Ground: 5' 6"

    Track Length: 7' 1"

  • Technical Specifications

    Operating Weight: 8,444 lb (Cab) / 8223 lb (Canopy)

    Ground Pressure:4.9 psi

    Engine: Yanmar 3TNV88F

    Displacement: 100.2 in3

    Net Power: 22.1 hp

    Gross Power: 23.2 HP

    Hydraulics: Load Sensing with Pilot Control

    Main Hydraulic Pump: Axial Piston - Variable Displacement

    Operating Flow (maximum): 23.2 gal/min

    Operating Pressure (maximum): 3553 psi

    Auxiliary Flow*: 18.5 gpm

    Auxiliary Pressure: 2901 psi

    Travel Motor: Axial Piston with Park Brake

    Travel Pressure (maximum): 3553 psi

    Travel Speeds (maximum): 1.5 / 2.6 mph

    Travel Effort (maximum): 8,273 lbf

    Grade Capability: 30º

    Swing Motor: Axial Piston with Swing Brake

    Swing Pressure (maximum): 2988 psi

    Swing Speed (maximum): 10 rpm

    Undercarriage (standard): Belted Rubber Track

    Track Shoe Width (standard): 12"

    Track Rollers (per side): 4

    Carrier Rollers (per side): 1

  • Working Range

    Boom Length : 6' 11"

    Stick (Arm) Length: 4' 3"

    Maximum Digging Height: 14' 6"

    Maximum Dumping Height: 10' 2"

    Maximum Digging Depth: 9' 3"

    Maximum Vertical Wall Digging Depth:

    8' 6"

    Maximum Reach at Ground Level: 15' 11"

    Minimum Swing Radius: 6' 11"

  • Digging Performance

    Boom Length: 8' 4"

    Stick Length: 4' 7"

    Bucket Breakout Force (ISO): 6,834 lbf

    Stick Digging Force (ISO): 4,092 lbf


    *Based on theoretical calculation at max flow with no load. Subject to alterations.
