Ride Control
Third-Function Auxiliary Plumbing
Z-Bar Linkage
Powershift Transmission
Duetz Engine
360 Degree Camera & Rear View Camera
Reversible Fan
Work Light Package & Beacon
Engine
Engine Model: Deutz TCD6.1
Max Gross Power : 181 hp
Net Engine Power: 163 hp
Max Gross Torque: 649 lbs ft
Displacement: 372 in3
Operating
Bucket Capacity: 3.2 yd3
Breakout Force: 27,652 lbf
Tipping Load Straight: 19,619 lbs
Tipping Load @ Full Term: 17,006 lbs
Clearance (full lift 45º dump): 8' 10"
Reach (full lift 45º dump): 3' 5"
Weight
Operating Weight: 31,967 lbs
Hydraulic System
Max Flow: 58 GP
Max Pressure: 3,916 PSI
Hydraulic Cycle Times
Raise: 5.6 sec
Dump: 1.6 sec
Float Down: 3.2 sec
Total Cycle Time: 10.4 sec
Service Capabilities
Fuel Tank: 60 gal
Cooling Systems : 8.7 gal
Engine Crankcase: 4.1 gal
Transmission: 14.5 gal
Front Axle: 9.2 gal
Rear Axle: 9.2 gal
Hydraulic Tank: 34 gal
DEF Tank: 2.6 gal
Transmission
Shift Modes: Automatic, Manual, Kick Down
Forward Gear 1-4: 4–25 mph
Reverse Gear 1-4: 4–17 mph
Power Train
Front Axle: Fixed
Traction Aid: Manual Differential Lock
Rear Axle: Oscillating
Traction Aid: Open Differential
Service Brakes: Wet Disc
Parking Brake: Disk Brake
Overall Dimensions
Ground Clearance: 1' 4"
Height to Top of Cab: 11' 2"
Center Line of Rear Axle to Edge of Counterweight: 6' 3"
Wheelbase: 9' 10"
Center Line of Front Axle to Center Pivot: 4' 10"
Shipping Length without Attachments: 20' 5"
Shipping Length with Bucket: 24' 8"
Max. Dump Height: 17' 2"
Hinge Pin Height at Max. Lift: 12' 7"
Dump Clearance at Max. Lift: 8' 10"
Dig Depth, Level Bucket: 4.8"
Reach at Max. Lift and 45º Discharge: 3' 5"
Roll Back at Max. Lift: 61º
Dump Angle at Max. Lift and Dump: 45º
Roll Back at Carry Height: 49º
Roll Back at Ground: 42º
Tail Angle to the Rear Wheel: 28º
Clearance Circle to Outside of Tires: 17' 8"
Clearance Circle to Counterweight: 17' 7"
Max. Circle: 19' 7"
Width: 6' 9"
Articulation Angle: +/- 40º
