1 and 2-Way Primary Auxiliary Hydraulic and 2-Way Rotate Auxiliary Hydraulic Piping and Case Drain
Powerful Cummins Engine
Backup Camera for Increased Visibility of The Jobsite
Led Cab, Boom and Side High-Intensity Work Lights
High-Strength Frame Guards To Protect The Upper Frame
Hydraulic Pilot Controls With Pattern-Control Selector
Segmented Track Guards To Keep Track In Place and Reduce Wear
Long, Heavy-Duty Undercarriage For Stability and Durability
Overall Dimensions
Boom Length: 20' 2"
Transport Length: 35'
Transport Width: 11' 2"
Transport Height: 11' 5"
Upper Structure Width: 10' 4"
Track Width (standard shoe): 31"
Track Gauge: 8' 6"
Ground Clearance (minimum): 24"
Tail Swing Radius: 10' 11"
Track Length: 16' 7"
Technical Specifications
Operating Weight: 74,075 lbs
Ground Pressure: 8.8 psi
Engine: Cummins L9 Stage V
Displacement: 598.0 in3
Gross Power: 280.3 HP
Hydraulics: Positive Flow System
Main Hydraulic Pump: Axial Piston Variable Displacement
Operating Flow (maximum): 147 gal/min
Operating Pressure (maximum): 4,975 psi
Travel Motor: *Axial Piston Motor w/Parking Brake
Travel Pressure (maximum): 4,975 psi
Travel Speeds (maximum): 2.1 / 3.2 mph
Travel Effort (maximum): 55,078 lbf
Grade Capability: 35°
Swing Motor: Axial Piston Motor w/Swing Brake
Swing Pressure (maximum): 3,989 psi
Swing Speed (maximum): 9.0 RPM
Undercarriage (standard): Steel Track
Track Shoe Width (standard): 31"
Track Rollers (per side): 9
Carrier Rollers (per side): 2
Working Range
Boom Length: 20' 2"
Stick (Arm) Length: 10' 6"
Maximum Digging Height: 34.5
Maximum Dumping Height: 24' 2"
Maximum Digging Depth: 22' 4"
Maximum Vertical Wall Digging Depth: 19'
Maximum Reach at Ground Level: 35' 8"
Minimum Swing Radius: 13' 1"
