Powerful Duetz Engine
Auxiliary Hydraulic Connections On The Boom
Single, Multi-Function Joystick Controls
Full 4-Wheel Fender Package
Backup Camera and Reverse Sensing System
Backup Camera and Reverse Sensing System
Cushioned Solid Tires
Led Boom Work Lights and Lift Hook
Overall Dimensions
Maximum Lift Height: 34' 1"
Maximum Forward Reach: 23'
Height, Stowed: 7' 11"
Length, Stowed (Without Forks): 7' 1'
Width: 7' 11"
Wheelbase: 10' 4"
Ground Clearance (Center): 1' 2"
Ground Clearance (Axle): 1'
Weight: 15,370 lbs
Performance
Maximum Lift Capacity: 6,000 lbs
Lift Capacity at Maximum Height: 4,000 lbs
Lift Capacity at Maximum Reach: 1,000 lbs
Boom (Raise/Lower): 9 seconds / 11 seconds
Boom (Extend/Retract): 14 seconds / 14 seconds
Frame Leveling: +/- 10 degrees
Maximum Drive Speed: 17 mph
Outside Turning Radius (4WS): 13' 9"
Auxiliary Hydraulic Flow: 16 gpm
Auxiliary Hydraulic Pressure: 2,466 psi
Standard Tire Size: 15.00/19.5
Capacities
Power: 74 hp
Torque: 192 lbf-ft
Electrical System: 24 volt
Hydraulic Tank Capacity: 18 gal
Hydraulic System Capacity: 34 gal
Fuel Tank Capacity: 36 gal
Components
Engine: Deutz TD 2.9
Transmission: Dana VDT12000
Axles F/R: Dana 212 / Dana 212
Hydraulic Pump: Casappa Load Sense Piston Pump
Hydraulic Manifold: Parker
