1 and 2-Way Primary Auxiliary Hydraulic and 2-Way Rotate Auxiliary Hydraulic Piping and Case Drain
Powerful Cummins Engine
Backup Camera for Increased Visibility of The Jobsite
Led Cab, Boom and Side High-Intensity Work Lights
High-Strength Frame Guards To Protect The Upper Frame
Hydraulic Pilot Controls With Pattern-Control Selector
Segmented Track Guards To Keep Track In Place and Reduce Wear
Long, Heavy-Duty Undercarriage For Stability and Durability
Overall Dimensions
Boom Length: 18' 8"
Transport Length: 31' 11"
Transport Width: 10' 5"
Transport Height: 11' 1"
Upper Structure Width: 8' 11"
Track Width (standard shoe): 31"
Track Gauge: 7' 10"
Ground Clearance (minimum): 19"
Tail Swing Radius: 9' 6"
Track Length on Ground: 11' 11"
Track Length: 14' 7"
Technical Specifications
Operating Weight: 51,919 lb
Ground Pressure: 5.3 psi
Engine: Cummins QSB6.7
Displacement: 408.9 in3
Gross Power: 163.6 HP
Hydraulics: Positive Flow Control with Pilot Control
Main Hydraulic Pump: Axial Piston - Variable Displacement
Operating Flow (maximum): 117.3 gal/min
Operating Pressure (maximum): 4,975 psi
Travel Motor: Axial Piston with Park Brake
Travel Pressure (maximum): 4,975 psi
Travel Speeds (maximum): 1.9/ 3.3 mph
Travel Effort (maximum: 40,466 lbf
Grade Capability: 35º
Swing Motor: Axial Piston with Swing Brake
Swing Pressure (maximum): 3,989 psi
Swing Speed (maximum): 10.9 rpm
Undercarriage (standard): Steel Track
Track Shoe Width (standard): 31"
Track Rollers (per side): 9
Carrier Rollers (per side): 2
Working Range
Boom Length: 18' 8 "
Stick (Arm) Length: 9' 7"
Maximum Digging Height: 30' 1"
Maximum Dumping Height: 21' 11"
Maximum Digging Depth: 21' 8"
Maximum Vertical Wall Digging Depth: 19' 7"
Maximum Reach at Ground Level: 33' 10"
Minimum Swing Radius: 12' 3"
