Boom Length: 9' 10"

Transport Length:19' 8"

Transport Width: 6' 7"

Transport Height: 8' 6"

Upper Structure Width: 6' 2"

Blade Height: 15"

Track Width (standard shoe): 16"

Track Gauge: 5' 3"

Ground Clearance (minimum): 13"

Tail Swing Radius: 5' 1"

Track Length on Ground: 6' 9"

Track Length: 8' 6"

Operating Weight:

13,228 lb

Ground Pressure

34.6 kPa

5.0 psi

Engine: Yanmar 4TNV98C

Displacement: 201.4 in3

Net Power: 55.1 HP

Gross Power: 56.9 HP

Hydraulics: Load Sensing with Pilot Control

Main Hydraulic Pump: Axial Piston - Variable Displacement

Operating Flow (maximum): 39.1 gal/min

Operating Pressure (maximum): 3,916 psi

Auxiliary Flow*: 23.8 gal/min

Auxiliary Pressure: 3,626 psi

Travel Motor: Axial Piston with Park Brake

Travel Pressure (maximum): 3,916 psi

Travel Speeds (maximum): 1.4 / 2.5 mph

Travel Effort (maximum): 13,713 lbf

Grade Capability: 30º

Swing Motor: Axial Piston with Swing Brake

Swing Pressure (maximum): 2,770 psi

Swing Speed (maximum): 9.6 rpm

Undercarriage (standard): Belted Rubber Track

Track Shoe Width (standard): 16"

Track Rollers (per side): 5

Carrier Rollers (per side): 1

Boom Length

3,000 mm

9' 10"

Stick (Arm) Length

1,700 mm

5' 7"

Maximum Digging Height

5,747 mm

18' 10"

Maximum Dumping Height

4,020 mm

13' 2"

Maximum Digging Depth

3,990 mm

13' 1"

Maximum Vertical Wall Digging Depth

3,220 mm

10' 6"

Maximum Reach at Ground Level

6,280 mm

20' 7"

Minimum Swing Radius

2,640 mm

8' 8"
