1 and 2-Way Primary Auxiliary Hydraulic and 2-Way Rotate Auxiliary Hydraulic Piping and Case Drain
Powerful Cummins Engine
Backup Camera for Increased Visibility of The Jobsite
Led Cab, Boom and Side High-Intensity Work Lights
High-Strength Frame Guards To Protect The Upper Frame
Hydraulic Pilot Controls With Pattern-Control Selector
Segmented Track Guards To Keep Track In Place and Reduce Wear
Long, Heavy-Duty Undercarriage For Stability and Durability
Overall Dimensions
Boom Length: 19' 4"
Transport Length: 33' 9"
Transport Width: 11' 1"
Transport Height: 10' 8"
Upper Structure Width: 10' 4"
Track width (standard shoe): 31"
Track Gauge: 8' 6"
Ground Clearance (minimum): 1' 6"
Tail Swing Radius: 10' 2"
Track Length on Ground: 12' 7"
Track Length: 15' 3"
Technical Specifications
Operating Weight: 59,525 lb
Ground Pressure: 5.7 psi
Engine: Cummins QSB 6.7T4F
Displacement: 408.9 in3
Gross Power: 194.4 HP
Hydraulics: Positive Flow Control with Pilot Control
Main Hydraulic Pump: Axial Piston - Variable Displacement
Operating Flow (maximum): 137.4 gal/min
Operating Pressure (maximum): 4,975 psi
Travel Motor: Axial Piston with Park Brake
Travel Pressure (maximum): 4,975 psi
Travel Speeds (maximum): 2.2 / 3.4 mph
Travel Effort (maximum): 51,032 lbf
Grade Capability: 35º
Swing Motor: Axial Piston with Swing Brake
Swing Pressure (maximum): 3,989 psi
Swing Speed (maximum): 10.6 rpm
Undercarriage (standard): Steel Track
Track Shoe Width (standard): 31"
Track Rollers (per side): 9
Carrier Rollers (per side): 2
Working Range
Boom Length: 19' 4 "
Stick (Arm) Length: 9' 8"
Maximum Digging Height: 31' 11"
Maximum Dumping Height: 22' 0"
Maximum Digging Depth: 22' 0"
Maximum Vertical Wall Digging Depth: 18' 7"
Maximum Reach at Ground Level: 33' 7"
Minimum Swing Radius: 12' 6"
